AETINA AN110 with NX Module

This product is a small, powerful computer for embedded applications and AI IoT that delivers the power of modern AI. The Camera Serial Interface (CSI) is based on MIPI CSI 2.0 standard specification can support up to 2xFull HD or 1x 4K camera. Suitable for NVR (Single Machine), Entry-level home robot and smart gateway.

Specifications

NX Processor

• NVIDIA® Jetson Xavier™ NX processing

• GPU: 384-core NVIDIA Volta™ GPU with 48 Tensor Cores

• CPU: 6-core NVIDIA Carmel ARM®v8.2 64-bit

  • CPU 6MB L2 + 4MB L3

• Memory: 8 GB 128-bit LPDDR4

• Storage: 16GB eMMC 5.1

• Performance: 14 TOPS (INT8) at 10W 21 TOPS (INT8) at 15W

• Dimension: 69.6 x 45mm(260-pin SO-DIMM connector)

AN110 Board Dimension

• 87.4 x 67.4mm

I/OInterface

• 1x HDMI Type A

• 1x RJ-45 for GbE

• 2x USB3.2 Gen1 Type A

• 1x USB2.0 Micro AB

• 1x Micro SD

• 1x FPC Camera connector(15pins/MIPI CSI 2Lanes)

• 1x FPC Camera connector(36pins/MIPI CSI 4Lanes)

• 1x Front Panel

• 1x RS-232 / 2 x UART / 1 x I2C / 5 x GPIO / 1x SPI

• 1x DC-in 12V (2 Pin Euroblock)

• 1x eDP (12V)

• 1x M.2 E key2230

Operating Temperature

• -25°C ~ +80°C (Board Standard temperature)

Operating Humidity

• 10% ~ 90%

Storage Temperature

• -40°C ~ +85°C

Accessories (Optional)

Block Diagram

Mechanical

AVL List
